Diesel 3000mm Lift Load 1500kg Reach Forklift Trucks

Product Categories
QINGDAO C AND C INTERNATIONAL TRADE CO., LTD
Contact Now

Diesel 3000mm Lift Load 1500kg Reach Forklift Trucks

  • 1
  • 2

Brand Name : CNC Hardware

Model Number : FD15 Diesel Forklift

Certification : CE/ ISO9001

Place of Origin : China

MOQ : 1 set

Payment Terms : T/T, L/C

Supply Ability : 200 sets per month

Delivery Time : 7 days

Packaging Details : pallet

Function : FD15 Diesel Forklift 3000mm Max Lift

Power Source : ISUZU Diesel Engine

Fork Length : 920mm

Fork Width : 100mm

Overall Dimensions : 2245x1070x1995mm

Load Center : 500mm

Ground clearance : 115mm

Wheel base : 1425mm

Load capacity : 1500kg

Max. lifting height : 3000mm-6000mm

Contact Now

Fork Size 920*100*35mm Mini 1.5 Ton FD15 Diesel Forklift With ISUZU Engine



Features of the Mini 1.5 Ton FD15 Diesel Forklift With ISUZU Engine

  • Original Isuzu C240 engine, high quality compliant with worldwide stage IIIA emission standard. The powerful engine ensures LTMG forklift truck high handing performance.
  • The standard LED lamps and warning lights make it safer, more energy efficient and create better working condition.
  • Thicker reinforcing plate ensures the safety and efficiency.
Specifications: Mini 1.5 Ton FD15 Diesel Forklift With ISUZU Engine
Specification 1 Manufacturer       CNCHardware
2 Model

Power shift

T/M

 FD15
3 Load capacity     kg 1500
4 Load center     mm 500
5 Power unit       diesel
6 Operator type       Driver/seat
7 Tire type       Pnenumatic
8 Wheel   Front/rear   2/2
Dimensions 9 Max. lifting height     mm 3000
10 Free lift     mm 155
11 Fork size   L×W×T mm 920*100*35
12 Tilt range   Mast forward/backward deg 6/12
13 Overall length (without fork)     mm 2245
14 Total width     mm 1070
15

Mast height

(fork lowering)

     mm 1995
16 Overall height fork raised (with backrest)     mm 4030
17 Height to head guard     mm 2060
18

Turning radius

(outside)

     mm 2040
19 Front face of fork to front axle     mm 395
20 Min. right angle stacking aisle     mm 2435
Performance 21 Speed Max Travelling full load km/h 14
no load km/h 14.5
22 Lifting full load mm/s 440
no load mm/s 500
23 Lowering full load mm/s 370
no load mm/s 530
24 Max. drawbar pull   full/no load Kg 1130/690
25 Gradeability at 1.6km/h   full/no load % 21/18
weights 26 Truck weight     kg 2550
27 Weight
distribution		 full load front kg 3580
rear kg 470
28 no load front kg 1110
rear kg 1440
Chassis & Wheels 29 front wheel       6.50-10-10PR
30 Rear wheel       5.00-8-10PR
31 Wheelbase     mm 1425
32 Tread front   mm 890
rear   mm 900
33 Ground
clearance		 At lowest point(mast)   mm 115
Frame   mm 105
34 Brake Service brake     Hydraulic-foot pedal
Parking brake     Mechanical-hand lever
Drive Line 35 Battery Voltage/capacity     12/80
36 Engine Model     ISUZU C240
Rated power   kw/rpm 34.3/2500
Rated torque   Nm/rpm 138/1800
Number of cylinders     4
Placement   L 2.369
37 Fuel tank capacity     L 50
38 Transmission Speed forward/backward     1-1 power shift T/M
39 Operating pressure Hydraulic system pressure   Kg/cm² 180



Diesel 3000mm Lift Load 1500kg Reach Forklift Trucks
